What internal parameters of the vortex flowmeter need to be set during specific use? The amplifier of the vortex flowmeter varies depending on its function and version.
1、 A vortex flowmeter with simple functions includes the following parameter options: instrument coefficient, small signal cutoff, 4-20mA corresponding output range, sampling or damping time, cumulative reset, etc.
2、 The vortex flowmeter with comprehensive functions, in addition to the above, also includes the following parameter options: type of measuring medium, flow compensation setting, flow unit, type of output signal, temperature upper and lower limits, pressure upper and lower limits, local gas pressure, medium standard density, communication settings (such as trigger number, baud rate, data bit, etc.). ~~Professional manufacturer and seller of flow meters, welcome to discuss and negotiate~
2. What are the measurement ranges of vortex flowmeters?
1、 Vortex flowmeter is a flowmeter based on the Karman vortex principle for measurement. It can measure liquids and gases, and is also very economical. The diameter is generally DN10-- DN1000. With temperature and pressure compensation, it can accurately measure gas or steam flow, and has a wide range of applications;
2、 Vortex flowmeter can only measure volumetric flow rate, usually in m3/h (cubic meters per hour), with instantaneous flow display and cumulative flow display;
3、 The measurement range corresponding to electromagnetic flow meters of different diameters is: liquid measurement: (unit: m3/h): DN15
1.2-6; DN20
1.5---10； DN25：2---16； DN32
1.8---20； DN40：2.5---25； DN50：3.5---40； DN65：7.5---70； DN80：12---130；
3. Actual flow rate of vortex flowmeter
The flow formula measured by vortex flowmeter is qv=π D2U/4=π D2mdf/4Sr K=f/qv=[π D2md/4Sr] -1. Under specific flow conditions, a part of the fluid kinetic energy is converted into fluid vibration, and the vibration frequency and flow rate (flow rate) of the vortex flowmeter have a certain proportional relationship. A flowmeter that works based on this principle is called a fluid vibration flowmeter. At present, there are three types of fluid vibration flow meters: vortex street flow meters, vortex precession flow meters, and jet flow meters. Fluid vibration flowmeter has the following characteristics: 1) The output is a pulse frequency, which is proportional to the actual volumetric flow rate of the measured fluid and is not affected by fluid composition, density, pressure, or temperature; 2) The measurement range is wide, and the general range can reach 10:1 or more; 3) The accuracy is above average level; 4) No movable parts, high reliability; 5) The structure is simple and sturdy, easy to install, and has low maintenance costs; 6) Widely applicable, suitable for liquids, gases, and vapors. The working principle is to set up a vortex generator (blocking fluid) in the fluid, and generate regular vortices alternately from both sides of the vortex generator. This type of vortex is called a Karman vortex street, as shown
