1. What are the components of an orifice flowmeter and can be directly put into use?
The structure of an integrated orifice flowmeter is divided into four parts:
1. Throttle components: standard orifice plate, standard nozzle, long diameter nozzle, 1/4 circular orifice plate, double orifice plate, eccentric orifice plate, circular orifice plate, conical inlet orifice plate, etc.
2. Pressure tapping device head: Bianqin Hu ring chamber, pressure tapping flange, clamping ring, pressure guiding pipe, etc.
3、 Connecting flanges (national standards, various standards, and flanges from other design departments) and fasteners.
4. Measuring tube.
2. Differences between Integrated Orifice Plate and Concealed Orifice Plate
Differences between Integrated Orifice Plate and Concealed Orifice Plate:
1. Integrated Orifice Plate: It is a differential pressure generating device for measuring flow rate, which can be used in conjunction with various differential pressure gauges or transmitters to measure the flow rate of various fluids in pipelines. The orifice plate flowmeter throttling device includes a ring chamber orifice plate, nozzles, etc.
2、 Hole plate hidden in the tunnel: It is a primary liquid flow element that, when combined with a differential pressure transmitter, forms a complete differential pressure flowmeter. Capable of measuring common small flow rates in factory metrology operations and research projects. Easy to install and cost-effective. It is widely used in industries such as steam boilers, petroleum, chemical, steel, electricity, water conservancy, papermaking, pharmaceuticals, food, and chemical fibers.
3. What are the commonly used steam fl
Steam flow meters are widely used, among which differential pressure flow meters and vortex flow meters are the most common.
. The differential pressure flowmeter measures flow through a throttling device, which commonly includes orifice plates, nozzles, Venturi tubes, averaging speed tubes, as well as Anubar, Velbar, and Probar. Balanced flowmeter is also a type of differential pressure flowmeter. Differential pressure flow meters are very common in practical applications, especially in steam flow measurement. To ensure measurement accuracy, temperature and pressure compensation is required for steam flow. The MVX100 multi variable amplitude integrated differential pressure flowmeter produced by Fross Company is highly favored. The advantage of this device is that it does not require external temperature and pressure compensation equipment, nor does it require an additional flow integrator, and can directly output mass flow. This integrated design simplifies the installation and maintenance process, improving the reliability and accuracy of the system. The MVX100 multivariable integrated differential pressure flowmeter is widely used in industrial production, energy management, and other fields, which can effectively improve the efficiency and accuracy of steam flow measurement. In addition to differential pressure flow meters, vortex flow meters are also a commonly used choice for measuring steam flow. The vortex flowmeter measures the flow velocity based on the frequency changes generated by the fluid flowing through the vortex street, and then calculates the flow rate. This flowmeter is suitable for high temperature and high pressure environments, and has advantages such as corrosion resistance a
