1. How to control water flow stability

The core solution for controlling water flow stability is to use a closed-loop control system, which monitors the flow rate in real time through sensors, calculates the deviation of the controller, and adjusts the actuator to achieve precise control.

1. The technical solution adopts a combination of PID controller (proportional integral derivative) and electromagnetic regulating valve, combined with turbine flowmeter or ultrasonic flowmeter, to form a closed-loop feedback system. The system response time is ≤ 2 seconds, and the control accuracy can reach ± 1.5%.

2. Key Implementation Path 1 Measurement unit • Flow meter selection: Turbine flow meter (accuracy ± 1%) is used for pipeline flow<10m ³/h, and ultrasonic flow meter (accuracy ± 0.5%) is used for pipeline flow ≥ 10m ³/h. Installation position: 10 times the pipe diameter upstream of the valve, ensuring full pipe flow Control unit • Core algorithm: Digital PID control, parameter tuning using Ziegler Nichols method • Controller: PLC (such as Siemens S7-1200) or dedicated flow controller (such as Siemens SITRANS FUE) 3. Execution unit • Electric regulating valve: Equal percentage characteristics, CV value selection based on 1.2 times the maximum flow rate • Stepper motor driver: subdivision accuracy ≥ 400 pulses/rev • Valve positioner: equipped with IP65 protection level

III. System parameter configuration • Sampling period: liquid medium setting 100-500ms • PID parameters: proportional band P: 20% -60% - integration time I: 0.1-10 minutes - differentiation time D: 0-2 minutes • Dead zone setting: ± 0.5% of the flow setting value to prevent oscillation Four knowledge balance, mechanical backup sche

Fifth, safety warning: Before debugging high-pressure pipelines (>1.6MPa), a pipeline pressure test must be conducted, with a test pressure of 1.5 times the working pressure. Electrical wiring must comply with the GB/T 5226.1-2019 standard to prevent the risk of electrical leakage. 6、 The latest industry standard refers to the technical requirements of GB/T 20207-2023 "Automatic Flow Control Valve", and HJ 1295-2023 "Technical Specification for Selection of Wastewater Flow Meter" implemented in 2024 specifies that ultrasonic flow meter is the recommended model.

2. Which is more useful for measuring similar water media, such as turbine flow meters, vortex street flow meters, or electromagnetic flow meters The advantages of electromagnetic flowmeter are minimal pressure loss and a wide range of measurable flow rates. The ratio of maximum flow rate to minimum flow rate is generally above 20:1, suitable for a wide range of industrial pipe diameters, up to 3m. The output signal is linear with the measured flow rate, with high accuracy. It can measure the fluid flow rate of acid, alkali, salt solutions, water, sewage, corrosive liquids, as well as mud, slurry, pulp, etc. with conductivity ≥ 5 μ s/cm. But it cannot measure the flow of gas, steam, and purified water. When a conductor cuts magnetic field lines in a magnetic field, an induced potential is generated in the conductor, and the magnitude of the induced potential is proportional to the effective length of the conductor in the magnetic field a
